| Company | NUVO |
|---|---|
| Bulb Included | Integrated |
| Dimmable Text | 0-10V Dimming Only |
| Extends (in) | 9.25 |
| Material | Die-cast Aluminum |
| Fixture Type | Wall Pack |
| Status | Obsolete |
| Style | Utility |
| Wire Quantity | 3 |
| CCT Selectable | No |
| Wattage Selectable | No |
| Finish Family | Bronze |
| Amps | 0.950-0.343A |
| Has Camera | No |
| IOT Enabled | No |
| Lens Finish | Frost |
| Lens Material | Glass |
| Photo Cell | Multiple Optional Sensors Available |
| Power Factor | 0.9 |
| SDS Class | LED_Fixture |
| Indoor Outdoor | Outdoor |
| Product Technology | LED |
| Incandescent Equivalent | 500W |
| CCT (Kelvin Temp) | 4000K |
|---|---|
| Dimmable | Yes-Dimmable |
| Hours Rated | 50000 |
| Color Temp | Cool White |
| CRI | 75+ |
| Dimming Type | 0-10V Dimming |
| Operating Temp | -30C (-22F) to +50C (+122F) |
| Lumens | 12065L |
| Volts | 120V-277V |
| Watts | 95W |
| Lamp Base | Integrated |
|---|---|
| Finish | BRONZE |
| ANSI Base | Integrated |
| Lamp Type | Integrated LED |
| Warranty | 5-Years |
|---|
| ADA Compliant | No |
|---|---|
| CA Prop 65 | Lead |
| FCC Compliant | Yes |
| IP Rating | IP65 |
| Location Rating | Wet |
| ROHS Compliant | Yes |
| Safety Listing | cETLus - Listed |
| California Ban | Lawful for sale |
| DLC Approved | No |
| Energy Star Certified | No |
| Title 20 | Exempt |
| T24 Compliant | No |
| UPC | 045923680472 |
|---|---|
| Case Cube | 1.4719 |
| Case Height | 11.61 |
| Case Length | 19.88 |
| Case Quantity | 1 |
| Case UPC | 10045923680479 |
| Case Weight | 12.57 |
| Case Width | 11.02 |
| EA Cube | 1.4719 |
| EA Height | 11.61 |
| EA Length | 19.88 |
| EA Quantity | 1 |
| EA Weight | 12.57 |
| EA Width | 11.02 |
| Inner Cube | 0.0 |
| Inner Height | 0.0 |
| Inner Length | 0.0 |
| Inner Quantity | 0 |
| Inner Weight | 0.0 |
| Inner Width | 0.0 |
| Pack Type | Box |
| Web Height | 9.0 |
| Web Width | 18.5 |
