| Status | Active |
| Watts | 12W |
| Incandescent Equivalent | 50W |
| Fluorescent Equivalent | 24W |
| Volts | 120V-277V |
| Ballast Type | Type B |
| Shape | T5 |
| Base | Miniature Bi Pin |
| ANSI Base | G5 |
| Nominal Length | 24 |
| Finish | Frost |
| CCT (Kelvin) | 3500K |
| Temperature | Neutral White |
| CRI | 83 |
| Lumens | 1400L |
| Beam Spread | 240 |
| Dimmable | Non-Dimmable |
| Hours Rated | 50000 |
| Product Category | Linear |
| Lamp Type | Linear |
| Technology | LED |
| Watts | 12W |
| Incandescent Equivalent | 50W |
| Fluorescent Equivalent | 24W |
| Volts | 120V-277V |
| Ballasting Requirements | Ballast Bypass |
| Ballast Type | Type B |
| Operating Frequency | 50/60Hz |
| CCT (Kelvin) | 3500K |
| Temperature | Neutral White |
| CRI | 83 |
| Lumens | 1400L |
| Beam Spread | 240 |
| Dimmable | Non-Dimmable |
| Power Factor | 0.9 |
| Hours Rated | 50000 |
| THD | 20% |
| Operating Temperature | -25C (-13F) to +45C (+113F) |
| MOL | 22.5 |
| MOD | 0.83 |
| Nominal Length | 24 |
| Shape | T5 |
| Base | Miniature Bi Pin |
| ANSI Base | G5 |
| Finish | Frost |
| Material | Glass |
| Lens Finish | Frost |
| Lens Material | Glass |
| Housing Color | White |
| Weight (lb.) | 0.21 |
| Shatter-Proof Type | PET Coated |
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| Warranty | 5 Year Limited - T5 LED Bulbs - Ballast Bypass |
| Safety Listing | cULus - Classified; cULus - Certified; ETLus - Sanitation Recognized Component |
| Location Rating | Damp |
| Energy Star | No |
| DLC Approved | No |
| DLC ID | FALSE |
| CA T20 / T24 Rationale | Exempt - Base Not Regulated |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| NSF Approved | Yes |
| SDS Sheet | LED Lamp |
| Each UPC | 045923286933 |
| Each Quantity | 1 |
| Each Length (in.) | 22.50 |
| Each Width (in.) | 0.85 |
| Each Height (in.) | 0.85 |
| Each Weight (lb.) | 0.20 |
| Each Cube (CuFt.) | 0.0094 |
| Pack Type | Sleeve |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923286930 |
| Case Quantity | 25 |
| Case Length (in.) | 24.50 |
| Case Width (in.) | 5.20 |
| Case Height (in.) | 5.20 |
| Case Weight (lb.) | 8.50 |
| Case Cube (CuFt.) | 0.3834 |
