| Status | Active |
| Watts | 25W |
| Incandescent Equivalent | 100W |
| Fluorescent Equivalent | 54W |
| Volts | Ballast Dependent |
| Ballast Type | Type A |
| Shape | T5 |
| Base | Miniature Bi Pin |
| ANSI Base | G5 |
| Nominal Length | 48 |
| Finish | Gloss |
| CCT (Kelvin) | 3500K |
| Temperature | Neutral White |
| CRI | 82 |
| Lumens | 3300L |
| Beam Spread | 185 |
| Dimmable | Yes-Dimmable |
| Hours Rated | 50000 |
| Product Category | Linear |
| Lamp Type | Linear |
| Technology | LED |
| Watts | 25W |
| Incandescent Equivalent | 100W |
| Fluorescent Equivalent | 54W |
| Volts | Ballast Dependent |
| Ballasting Requirements | Ballast required |
| Ballast Type | Type A |
| Operating Frequency | 50/60Hz |
| CCT (Kelvin) | 3500K |
| Temperature | Neutral White |
| CRI | 82 |
| Lumens | 3300L |
| Beam Spread | 185 |
| Dimmable | Yes-Dimmable |
| Dimming Note | Only in Type A mode; Check Ballast MFG for Dimmer Compatibility |
| Power Factor | 0.9 |
| Hours Rated | 50000 |
| THD | 20% |
| Operating Temperature | -20C (-4F) to +45C (+113F) |
| MOL | 46 |
| MOD | 0.63 |
| Nominal Length | 48 |
| Shape | T5 |
| Base | Miniature Bi Pin |
| ANSI Base | G5 |
| Finish | Gloss |
| Material | Aluminum / Glass |
| Lens Finish | Gloss |
| Weight (lb.) | 0.3 |
| Additional Info | Light Emitting Area of 325 degrees; System Wattage (Type A) - 28W |
| Includes | Integrated thermal fuse at pins |
| Integrated Features | Integrated thermal fuse at pins |
| Installation Notes | Not for use in vapor tight fixtures. |
| Rated For Enclosed Fixture | Yes |
| Warranty | 5 Year Limited - T5 LED Bulbs |
| Safety Listing | cULus - Listed |
| Location Rating | Damp |
| Energy Star | No |
| DLC Approved | Yes |
| DLC ID | PLF2500Z49X9 |
| CA T20 / T24 Rationale | Exempt - Base Not Regulated |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| NSF Approved | Yes |
| SDS Sheet | LED Lamp |
| Each UPC | 045923299124 |
| Each Quantity | 1 |
| Each Length (in.) | 47.60 |
| Each Width (in.) | 0.59 |
| Each Height (in.) | 0.59 |
| Each Weight (lb.) | 0.51 |
| Each Cube (CuFt.) | 0.0096 |
| Pack Type | Sleeve |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923299121 |
| Case Quantity | 10 |
| Case Length (in.) | 48.40 |
| Case Width (in.) | 6.30 |
| Case Height (in.) | 3.54 |
| Case Weight (lb.) | 5.13 |
| Case Cube (CuFt.) | 0.6247 |
