| Status | Active |
| Watts | 13W |
| Incandescent Equivalent | 50W |
| Fluorescent Equivalent | 28W/32W |
| Volts | 120V-277V |
| Ballast Type | Type A/B |
| Shape | T8 |
| Base | Medium Bi Pin |
| ANSI Base | G13 |
| Nominal Length | 48 |
| Finish | Frost |
| CCT (Kelvin) | 3000K |
| Temperature | Warm White |
| CRI | 83 |
| Lumens | 1850L |
| Beam Spread | 180 |
| Dimmable | Yes-Dimmable |
| Hours Rated | 50000 |
| Product Category | Linear |
| Lamp Type | Linear |
| Technology | LED |
| Watts | 13W |
| Incandescent Equivalent | 50W |
| Fluorescent Equivalent | 28W/32W |
| Volts | 120V-277V |
| Ballasting Requirements | Ballast required (Type A) or Ballast Bypass (Type B) |
| Ballast Type | Type A/B |
| Operating Frequency | 50/60Hz |
| CCT (Kelvin) | 3000K |
| Temperature | Warm White |
| CRI | 83 |
| Lumens | 1850L |
| Beam Spread | 180 |
| Dimmable | Yes-Dimmable |
| Dimming Note | Only in Type A mode; Check Ballast MFG for Dimmer Compatibility |
| Power Factor | 0.96 |
| Hours Rated | 50000 |
| THD | 20% |
| Operating Temperature | -20C (-4F) to +45C (+113F) |
| MOL | 47.78 |
| MOD | 1 |
| Nominal Length | 48 |
| Shape | T8 |
| Base | Medium Bi Pin |
| ANSI Base | G13 |
| Finish | Frost |
| Material | Glass |
| Lens Finish | Frost |
| Housing Color | White |
| Weight (lb.) | 0.53 |
| Shatter-Proof Type | PET Coated |
| Installation Notes | Not for use in vapor tight fixtures. |
| Specification Note | Ballast Compatible - bare lamp is 12W; Ballast Bypass - 13W.; Protection from arcing- Power must be turned off prior to installing lamps. Sockets must be in good working order, not broken, cracked or electrically compromised. If arcing occurs at the lamp pin, thermal fuse may activate to avoid overheating of lamp. |
| Rated For Enclosed Fixture | Yes |
| Warranty | 5 Year Limited - T8 LED Bulbs |
| Safety Listing | cULus - Listed; cULus - Classified; ETLus - Sanitation Recognized Component |
| Location Rating | Damp |
| Energy Star | No |
| DLC Approved | Yes |
| DLC ID | PL20BPLJYLDH |
| CA T20 / T24 Rationale | Exempt - Base Not Regulated |
| RoHS Compliant | Yes |
| FCC Compliant | Yes |
| NSF Approved | Yes |
| SDS Sheet | LED Lamp |
| Each UPC | 045923088902 |
| Each Quantity | 1 |
| Each Length (in.) | 48.00 |
| Each Width (in.) | 1.10 |
| Each Height (in.) | 1.10 |
| Each Weight (lb.) | 0.50 |
| Each Cube (CuFt.) | 0.0336 |
| Pack Type | Sleeve |
| Inner Quantity | 0 |
| Inner Length (in.) | 0.00 |
| Inner Width (in.) | 0.00 |
| Inner Height (in.) | 0.00 |
| Inner Weight (lb.) | 0.00 |
| Inner Cube (CuFt.) | 0.0000 |
| Case UPC | 10045923088909 |
| Case Quantity | 25 |
| Case Length (in.) | 50.20 |
| Case Width (in.) | 7.30 |
| Case Height (in.) | 7.30 |
| Case Weight (lb.) | 15.90 |
| Case Cube (CuFt.) | 1.5481 |
