Discontinued – Suggested Replacement: S28938R1
S8937 110W/LED/HID/SB/3K/E39/100-277

S8937

110W/LED/HID/SB/3K/E39/100-277

110 Watt LED Hi-lumen shoe box style lamp for commercial fixture applications; 3000K; Mogul base; 100-277 Volt


Lights

S8937

110W/LED/HID/SB/3K/E39/100-277

110 Watt LED Hi-lumen shoe box style lamp for commercial fixture applications; 3000K; Mogul base; 100-277 Volt

Specifications

General
StatusDiscontinued
SubstituteS28938R1
Watts110W
Incandescent Equivalent1760W
HID Equivalent400W
Volts100V-277V
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishClear
CCT (Kelvin)3000K
TemperatureWarm White
CRI80+
Lumens14000L
Beam Spread180
DimmableNon-Dimmable
Hours Rated50000
Product CategoryCorncob
Lamp TypeCorncob
TechnologyLED
Min Compartment SizeLength: 11.3 in. Width: 11 in. Depth: 11 in.
Ballasting RequirementsBallast Bypass
Electrical
Watts110W
Incandescent Equivalent1760W
HID Equivalent400W
Volts100V-277V
Ballasting RequirementsBallast Bypass
Operating Frequency50/60Hz
CCT (Kelvin)3000K
TemperatureWarm White
CRI80+
Lumens14000L
Beam Spread180
DimmableNon-Dimmable
Power Factor>0.9
Hours Rated50000
Operating PositionHorizontal
Operating Temperature-30C (-22F) to +45C (+113F)
Physical
MOL11.06
MOD4.38
ShapeCorncob
BaseMogul
ANSI BaseE39
FinishClear
Lens FinishClear
Housing ColorWhite
Additional Information
Min Compartment SizeLength: 11.3 in. Width: 11 in. Depth: 11 in.
Rated For Enclosed FixtureYes
IP RatingIP64
Installation NotesNot for use in vapor tight fixtures.
Warranty5 Year Limited - Hi-Pro
Compliance
Safety ListingcULus - Certified; cULus - Classified
Location RatingDamp
DLC ApprovedNo
RoHS CompliantYes
FCC CompliantYes
SDS SheetLED Lamp
Packaging
Each UPC045923089374
Each Quantity1
Each Length (in.)12.69
Each Width (in.)5.71
Each Height (in.)6.30
Each Weight (lb.)4.72
Each Cube (CuFt.)0.2642
Pack TypeBox
Inner Quantity0
Inner Length (in.)0.00
Inner Width (in.)0.00
Inner Height (in.)0.00
Inner Weight (lb.)0.00
Inner Cube (CuFt.)0.0000
Case UPC10045923089371
Case Quantity4
Case Length (in.)13.28
Case Width (in.)12.02
Case Height (in.)13.20
Case Weight (lb.)20.24
Case Cube (CuFt.)1.2194
